31
d. Remove the wedge from the feeder as shown below.
Gently lift and hold suction
cup arm with one hand...
1
Then slide wedge out
with other hand
2
Bottom of feeder
Wedge
Front of feeder
Inside of feeder
Gently lower
suction cup arm
3
IMPORTANT: Save the carton and all packing materials. If you
need to ship the digitizer later, you must repack it using the
original wire ties, plastic bags, foam supports and cartons.
Instructions for repacking are provided in “Appendix: Packing
the film digitizer for shipment.”
VIDAR CADPRO Advantage Installation Guide
