Assemble the digitizer
1.
Place the stand on a solid, flat surface (such as a table
).
2.
Place the digitizer base on the stand as shown below. T
ighten the
thum
bscr
ews
on the bottom
of the stand to secure it to the digitizer
.
Front view Side view
Front
*
Thumbscrews (2) Longer portion toward front
*V
ent in bottom o
f base
m
ust be over
cutout in stand
