About films
The film
digitizer handles standard 18cm x 24cm and 24cm x 30cm
mammography film
s.
Y
ou can feed m
u
ltiple films (up to 50 or 100, depending on the feeder),
and you can mix fil
m sizes.
IMPORTANT: Remove stickers, tape, staples, paper clips, etc.
from films before scanning. These may cause serious film
feeding problems and may damage the digitizer’s internal
mechanisms. Failure to remove extraneous items from
films will void your warranty.
T
o prepare films for digitizing:
Stack each group of films according to the sequence specified by the
CAD sy
stem
manufacturer. A typical sequence is shown below.
Place a separator in each group. Use separators approved by the CAD
system manufacturer.
18cm long x 24cm wide film stack 30cm long x 24cm wide film stack
VIDAR Advantage Series Installation and Operation Guide
