Name Declara-
tion
Data type Address
(Inst.-DB)
Default
value
Comment
JOB_REQ INPUT BOOL 8.0 FALSE Initiates the job (edge 0-1)
JOB_ID INPUT WORD 10.0 0 Job ID
JOB_VAL INPUT DINT 12.0 0 Value for write jobs
STS_EN OUTPUT BOOL 16.0 FALSE Status of the internal gate
JOB_DONE OUTPUT BOOL 16.3 TRUE New job can be started.
JOB_ERR OUTPUT BOOL 16.4 FALSE Job error
JOB_STAT OUTPUT WORD 18.0 0 Job error ID
Name Data type Address
(Instance DB)
Default Comment
JOB_OVAL DINT 20.0 - Output value for read request.
Per channel you may call the SFB in each case with the
same instance DB, since the data necessary for the
internal operational are stored here. Writing accesses to
outputs of the instance DB is not permissible.
To read/write the registers of the pulse width modulation the request
interface of the SFB 49 may be used.
So that a new job may be executed, the previous job must have be
finished with JOB_DONE = TRUE.
The deployment of the request interface takes place at the following
sequence:
Local data only in
Instance DB
PWM Request interface
Proceeding
VIPA System 300SDeployment I/O periphery
Pulse width modulation - PWM > SFB 49 - PULSE - Pulse width modulation
HB140 | CPU-SC | 312-5BE13 | GB | 15-50 130
