VIPA CPU 312SC - Hardware description; Properties

4 Hardware description
4.1 Properties
n SPEED7 technology integrated
n 64kbyte work memory integrated (32kbyte code, 32kbyte data)
n Work memory expandable to max. 512Mbyte (256kbyte code,
256kbyte data)
n 512kbyte load memory
n RS485 interface for PtP communication
n Ethernet PG/OP interface integrated
n MPI interface
n MCC slot for external memory cards (lockable)
n Status LEDs for operating state and diagnostics
n Real-time clock battery buffered
n Digital I/Os: DI 16xDC24V / DO 8xDC 24V, 0.5A
n 2 channels for counter, frequency measurement and pulse width
modulation
n I/O address range digital/analog 1024byte
n 512 timer
n 512 counter
n 8192 flag byte
Type Order number Description
312SC 312-5BE13 MPI interface, card slot, real time clock, Ethernet
interface for PG/OP, DI 16xDC24V / DO 8xDC24V,
0.5A, 2 channels technological functions
CPU 312-5BE13
Ordering data
VIPA System 300SHardware description
Properties
