5.9.2 Transfer via Ethernet
For transfer via Ethernet the CPU has the following interface:
n X5: Ethernet PG/OP channel
So that you may access the Ethernet PG/OP channel you have to
assign IP address parameters by means of the "initialization".
Ä
‘Hardware configuration - Ethernet PG/OP channel’ on page 50
1. For the transfer, connect, if not already done, the appropriate
Ethernet port to your Ethernet.
2. Open your project with the Siemens SIMATIC Manager.
3.
Set via ‘Options è Set PG/PC Interface’ the access path to
"TCP/IP ® Network card .... ".
4.
Click to ‘PLC è Download
’ Download ® the dialog "Select
target module" is opened. Select your target module and enter
the IP address parameters of the Ethernet PG/OP channel for
connection. Provided that no new hardware configuration is
transferred to the CPU, the entered Ethernet connection is per-
manently stored in the project as transfer channel.
5. With [OK] the transfer is started.
System dependent you get a message that the projected
system differs from target system. This message may be
accepted by [OK].
®
Your project is transferred and may be executed in the
CPU after transfer.
5.9.3 Transfer via MMC
The MMC (Memory Card) serves as external transfer and storage
medium. There may be stored several projects and sub-directories on
a MMC storage module. Please regard that your current project is
stored in the root directory and has one of the following file names:
n S7PROG.WLD
n AUTOLOAD.WLD
With ‘File è Memory Card File è New
’ in the Siemens SIMATIC
Manager a new wld file may be created. After the creation copy the
blocks from the project blocks folder and the System data into the wld
file.
The transfer of the application program from the MMC into the CPU
takes place depending on the file name after an overall reset or Pow-
erON.
n S7PROG.WLDis read from the MMC after overall reset.
n AUTOLOAD.WLD is read after PowerON from the MMC.
Initialization
Transfer
Transfer MMC ® CPU
VIPA System 300SDeployment CPU 312-5BE13
Project transfer > Transfer via MMC
HB140 | CPU-SC | 312-5BE13 | GB | 15-50 56
