VIPA CPU 312SC - Communication

1: 1bit 2: 1.5bit 3: 2bit
The parameter FLOWCONTROL is ignored. When sending RTS=1,
when receiving RTS=0.
Return values send by the block:
Error
code
Description
0000h no error
809Ah Interface not found e. g. interface is used by PROFIBUS
In the VIPA SLIO CPU with FeatureSet PTP_NO only the
ASCII protocol is configurable. If another protocol is
selected the FC/SFC216 also left with this error code.
8x24h Error at FC/SFC-Parameter x, with x:
1: Error at PROTOCOL
2: Error at PARAMETER
3: Error at BAUDRATE
4: Error at CHARLENGTH
5: Error at PARITY
6: Error at STOPBITS
7: Error at FLOWCONTROL
809xh Error in FC/SFC parameter value x, where x:
1: Error at PROTOCOL
3: Error at BAUDRATE
4: Error at CHARLENGTH
5: Error at PARITY
6: Error at STOPBITS
7: Error at FLOWCONTROL (parameter is missing)
8092h Access error in parameter DB (DB too short)
828xh Error in parameter x of DB parameter, where x:
1: Error 1. parameter
2: Error 2. parameter
...
7.5 Communication
7.5.1 Overview
The communication happens via the send and receive blocks FC/
SFC 217 (SER_SND) and FC/SFC 218 (SER_RCV). The FCs/SFCs
are included in the consignment of the CPU.
FLOWCONTROL
RETVAL FC/SFC 216
(Return values)
VIPA System 300SDeployment PtP communication
Communication> Overview
HB140 | CPU-SC | 312-5BE13 | GB | 15-50 146
