Byte Bit 7...0
8 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+0.0
n Bit 1: 0 (fix)
n Bit 2: ... input I+0.1
n Bit 3: 0 (fix)
n Bit 4: ... input I+0.2
n Bit 5: 0 (fix)
n Bit 6: ... input I+0.3
n Bit 7: 0 (fix)
9 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+0.4
n Bit 1: 0 (fix)
n Bit 2: ... input I+0.5
n Bit 3: 0 (fix)
n Bit 4: ... input I+0.6
n Bit 5: 0 (fix)
n Bit 6: ... input I+0.7
n Bit 7: 0 (fix)
10 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+1.0
n Bit 1: 0 (fix)
n Bit 2: ... input I+1.1
n Bit 3: 0 (fix)
n Bit 7 ... 4: reserved
11 ... 15
n Bit 7... 0: reserved
