Event-ID Description
0xEA64 PROFINET/EtherCAT CP
Configuration error: Zinfo1:
Bit 0: Too many devices
Bit 1: Too many devices per ms
Bit 2: Too many input bytes per ms
Bit 3: Too many output bytes per ms
Bit 4: Too many input bytes per device
Bit 5: Too many output bytes per device
Bit 6: Too many productive connections
Bit 7: Too many input bytes in the process image
Bit 8: Too many output bytes in the process image
Bit 9: Configuration not available
Bit 10: Configuration not valid
Bit 11: Cycle time too small
Bit 12: Cycle time too big
Bit 13: Not valid device number
Bit 14: CPU is configured as I device
Bit 15: Obtain an IP address in a different way is not supported for the IP
address of the controller
0xEA65 Internal error - Please contact the VIPA Hotline!
0xEA66 PROFINET IO controller
Error in communication stack
PK: Rackslot
OBNr: StackError.Service
DatId: StackError.DeviceRef
ZInfo1: StackError.Error.Code
ZInfo2: StackError.Error.Detail
ZInfo3: StackError.Error.AdditionalDetail
<< 8 + StackError.Error.AreaCode
0xEA67 Error - PROFINET IO controller - reading record set
PK: Error type
0: DATA_RECORD_ERROR_LOCAL
1: DATA_RECORD_ERROR_STACK
2: DATA_RECORD_ERROR_REMOTE
OBNr: PROFINET IO controller slot
DatId: Device-No.
ZInfo1: Record set number
ZInfo2: Record set handle
ZInfo3: Internal error code for service purposes
VIPA System 300S Deployment CPU 312-5BE13
VIPA specific diagnostic entries
HB140 | CPU-SC | 312-5BE13 | GB | 15-50 79
