Viper AS510B User Manual

USER MANUAL
11
recovery tank cover (25), and press the power switch (41 and 42) to turn on
the main power and the vacuum motor.
Recovery tank emptying
1. Turn off the machine.
2. Raise the squeegee assembly (14).
3. Move the machine to a dedicated draining location.
4. Grasp the handle (2) and tilt the machine backward until the
guide wheel touches the floor.
5. Remove the drain hose from the clip, bend the top end of
draining hose (A, Figure 13), and then remove the drain
hose cap. Lower the hose to a low level or on the ground to
drain the water. Alternatively, place drain hose to a low
position or on the ground to make the water outlet face
downward (B, Figure 13), and then twist open the drain cap
to drain the wastewater in the tank. After draining is
completed, rinse the inside of recovery tank with clean
water
CAUTION
！
！！
！
When draining the wastewater, the drain hose must be folded or lowered to a lower
position (Figure 13 A or B), and the cap removed for wastewater to drain. Do not
allow the opening of the drain hose to face upward, as it could get wastewater on the
operator.
.
Solution tank emptying
6. Complete Steps 1 to 4.
7. As shown in Figure 14, turn open the lid of Solution tank (A)
counter clockwise (direction C), to drain Solution tank completely.
Use clean water to rinse the inside of Solution tank. When work is
completed, replace the solution tank lid (A) by twisting in a
clockwise in direction (B).
AFTER EACH USE
When work is done and before leaving the machine, completes the
following steps:
1. Remove the brush / pad holder.
2. Drain solution tank & rinse with clean water.
3. Drain recovery tank & rinse with clean water.
4. Complete the daily maintenance procedures. (see maintenance
section)
5. Remove and rinse squeegee assembly with damp towel.
6. Keep recovery tank lid unsealed from tank to allow fresh air to circulate freely
PERIODS OF INACTIVITY
If the machine is not to be used for more than 30 days, please treat it in the following way:
1. Complete the necessary procedure that should be followed after the machine is used.
2. Disconnect the connector (9) connecting the battery and the machine.
3. In order not to damage the batteries, the batteries should be charged once every 3 months.
USING FOR THE FIRST TIME
After the first 9 hours of use, please check components to ensure all connections (electrical &
mechanical) are tight & check for any damage that may have occurred during operation. Check for
water leakage.
Figure 14
Figure 13
