USER MANUAL
4
TECHNICAL DATA
Model AS510B
Machine Height 980mm
Solution tank capacity 40 litre
Recovery tank capacity 40 litre
Diameter of transport wheel 200mm
Diameter of guide wheel 76mm
Power of vacuum system motor 350w
Maximum gradient when working
2
％
(Max)
Sound pressure level at workstation
70dB(A
）
±3dB(A)
Standard batteries (2×12V) 24V 105Ah AGM
Battery compartment size (W x L x H) 340 x 330 x 260mm(Max)
Vacuum system circuit capacity
1200 mm H
2
O
Cleaning width
510mm
Squeegee width
790mm
machine maximum length
1100mm
Machine width without squeegee
540mm
Brush diameter
510mm
Weight with batteries and with empty tanks
128kg
Gross weight of the machine ready for use
168kg
Brush motor power
560W
Brush speed
150rpm
Brush /pad-holder Maximum pressure
35kg(Max)
Packing size (Lx W x H)
1200 x 610 x 1170mm
MACHINE DESCRIPTION
MACHINE EXPLODED VIEW
1.
Safety switch button 20. Squeegee adjusting knob
2.
Handle 21. Squeegee rear support frame
3.
Control panel 22. Squeegee front support frame
4.
Serial number plate/Technical data 23. Cup holder
5.
Control cover 24. Recovery tank cover handle
6.
Cable holder (*) 25. Recovery tank lid
7.
Battery charging indication light 26. Recovery tank
8.
Reset switch 27. Solution fill
9.
Battery connector 28. Brush deck
10.
Battery cover 29. Brush / pad-holder
11.
Drain hose 30. Vacuum motor
12.
Squeegee lift cable 31. Brush motor
13.
Battery connector safety cover 32. 8” wheel
14.
Squeegee lift handle 33. Battery
15.
Drain cap 34. Vacuum tube
16.
Squeegee knob 35. Charger (*)
17.
Squeegee clip 36. Float filter
18.
Squeegee blade 37. Water level site tube
19.
Squeegee bracket
(*) applicable only to machines already installed with on-board charger (optional)
