Viper AS510B - Page 20

Item Part No. Description Qty
TANK SYSTEM
AS510B PART LIST
37 VF90235 SCEREW TM4x10 2
38 VF90508 SUCTION HOSE 2
39 VF90246 BATTERY CABLE KIT 1
40 VF90231 GASKET 1
41 VF90214 SEAL PLATE COVER 2
42 VF90217 SEAL PLATE 2
43 VA80758 SCREW 4
44 VF90529 SUCTION TUBE CONNECTER 1
45 VF90528 DRAIN HOSE CONNECTOR 1
46 VF90512 SUCTION TUBE GASKET 3
47 VF90509 SEALING KNOB 2
48 VA20304 CLAMP 4
49 VF90534 FLOAT KIT 1
50 VF90530 CAGE,FLOAT COMPLETE 1
51 VF90526 FLOAT BRACKET 1
52 VF85124 FLOATE 1
53 VF90527 FLOATE BRACKET COVER 1
54 VF90218 CONTROL SEAL GASKET 1
55 VF90401 DRAIN HOSE CONNECTER 1
56 VF83150 HOLDER,"U"HOSE 1
57 VF90443 DRAIN HOSE-38 1
58 VF90235 SCEREW TM4x10 2
59 VA13483 WASHER ￠ 4 2
60 VF90514 BATTERY BRACKET 1
61 N/A BATTERY 12V 105Ah/20h AMG 2
62 GT13054 SCEREW TM5x12 4
63 VF90814 BATTERY COVERY 1
64 VF90254 MOTOR CABLE ASSEMBLY 1
65 VF90247 POWER CABLE 1
66 VF90026 WARNING LABEL 1
19
