Organ controls settings (Setup / Controls menu)
ORGAN CONTROLS SETTINGS (SETUP / CONTROLS menu)
The CONTROLS menu contains all the settings relating to the controls available
in the organ console.
To access to this menu, in the main video page,
1. press the [MENU/ENTER] button,
2. place the cursor on the SETUP field and press [MENU/ENTER],
3. place the cursor on the CONTROLS field and press [MENU/ENTER].
The CONTROLS menu contains the following settings:
Parameter name
Description
ENC Config
Select the expression pedal that regulates the volume of each section while the [ENC] piston is
on.
To access the adjustment screen, press [MENU/ENTER] while ENC CONFIG field is displayed:
The organ sections can be found on the left side, while on the right the expression pedal can be
selected.
Settings: Free (no control), [organ division]
Swellbox Steps
Number of swellbox steps for each organ division
To access the adjustment screen, press [MENU/ENTER] while SWELLBOX STEPS field is
displayed:
Settings: 4, 8, 16, Full (continuous control)
Crescendo Pedal
[CRESCENDO] pedal operating mode.
Settings: On, Off, I/PD Shoe (Man.I/Pedal expression pedal)
Link Master Volume
Pot. To
Which volume is controlled by the [MASTER VOLUME] potentiometer, placed under the manuals.
Settings:
• Int Gen Vol: internal amplification volume only.
• Int+Ext Vol: volume of both the internal amplification and of the signal of the rear outputs [PROG.
OUT].
• Ext Vol: volume of the signal of the rear outputs [PROG. OUT] only.
• Nothing: no control
Orchestra Couplers
Selection if coupler affects the orchestral voices.
Settings: No, Yes
