VM1000C Pilot’s Guide Page
31
Use the J5 connector harness 790719-X labeled FUELP. Mount the
pressure sensor to the pressure line using a 6-inch flexible hose and
fittings (not supplied) as depicted in the drawing below. Use tie-wraps to
mount the pressure sensor an engine mount structure. Do not mount the
sensor directly to the engine. Connect the other end of the hose to the
existing pressure line. Later, you will connect the pressure sensor to the
four pressure sensor wires through the supplied 4-pin connector. Part No.
790719 required for Carburetor engines PN 306017 for injected engines
RPM Sensor installation
Use the J3 connector harness 790420 and connect the 3 leads using
the supplied 3-pin connector and pins. Mount the sensor as shown in
the diagram below.
Ammeter Shunt Installation
Use the J5 connect harness 790719-X labeled AMP+ and AMP-. Connect
the harness leads using ring terminals to the smaller terminal screws on
the side of the shunt.
Charge/Discharge configuration. The shunt can be installed between
the master contactor and the main bus in which case it will be in the
ammeter configuration showing battery charge and discharge. Be sure
that the positive side of the shunt is connected to the main bus in the
