VM1000C Pilot’s Guide Page
3
is greater than 1500. The engine hour counter is initialized by
performing the ENGINE HOURS setup. Page 41
RPM Alert
A warning alert activates whenever
the engines redline is reached (as set
in ENGINE LIMITS menu). The
RPM display will flash until this
condition is corrected. Page 43
Manifold Pressure Operation
The manifold pressure system provides both a full sweep color
graphic analog display and three place digital display. The full color
range marks provide you with a quick reference to when making fast
power changes.
The digital readout provides you with precise information. This
allows very precise power settings to be achieved and is useful for
new induction system designs, or modifications to existing designs,
where repeatability and accuracy is a must.
Note: If %HP icon is shown, then the VM1000C is in percent
power mode. To change to the Manifold Pressure mode simply
hold
in until you see the MAN icon appear.
Manifold Pressure Alert
A warning alert activates whenever the engine’s redline is reached
(as set in ENGINE LIMITS menu section 50.0 user defined engine
parameters). The display will flash until this condition is corrected.
Manifold Pressure Calibration (Optional)
Manifold Pressure can be fine-tuned to your installation in the
appropriate MISCELLANEOUS menu item.
