D-302541 3
1. INTRODUCTION
The PowerMax Pro is a user and installer-friendly, 30-zone
fully-supervised wireless control system. The system is
designed to function in a way that appeals to the user but
also offers features that make installers’ life easier than
ever before.
The PowerMax Pro includes an optional partition feature.
Partitioning allows you to have up to three independently
controllable areas with different user codes assigned to each
partition or one user code assigned to a combination of up
to 3 partitions.
Partitions can be armed or disarmed
individually or altogether in one operation. For example, you
can define the garage as partition 1, the basement as partition
2 and the house as partition 3. Since each partition is
independent of other partitions, you can arm or disarm each
partition as desired without altering the states of the other
partitions.
EASY TO INSTALL
• Plug-in terminal blocks in "Zones", "Dual RS-232" and
"Phone" modules, can be wired while detached from the
unit.
• Quick attach-detach TELCO sockets for telephone line
and X-10 controller. Includes a terminal block for
telephone line & set.
• Special wall-mounted bracket permits installation without
having to open the unit’s plastic casing.
• Optional plug-in dual RS-232 module that enables a
concurrent connection of a PowerLink or local computer
(only 2 simultaneous device connections).
EASY TO MAINTAIN
• Status, alarm memory and trouble data are displayed
upon request.
• Diagnostic test provides visual and audible indication of
the signal level of each detector.
• Remote control and status verification from distant
telephones.
• Event log stores and displays information on 100 most
recent events.
• Upload / download from distant computer via telephone
line and modem.
QUICK PROGRAMMING
• Multiple-choice selection of options for each parameter.
• Unequivocal visual prompts and audible signals.
• Installer access to the user menu.
2. SPECIFICATIONS
2.1 General Data
Zones Number: 28 wireless, 2 hardwired (zones 29 & 30).
Hardwired Zone Requirements: 2.2 kΩ E.O.L. resistance
(max. resistance of wires 220 Ω).
Zone Types: Interior follower, interior, perimeter, perimeter
follower, delay 1, delay 2, 24h silent, 24h audible, fire, non-
alarm, emergency, gas, flood, temperature and home /
delay.
User Codes: 8 codes, 4 digits each (9999 different
combinations). Code 0000 is not allowed.
Control Facilities:
- Integral keypad
- PowerCode / Code-Secure™ hand-held transmitters
- One-way / two-way keypads
- Optional Built-In Proximity Tag Reader
- Web interface via optional PowerLink module
- SMS commands via optional GSM/GPRS module
- Remote control by telephone
Display: Single line, Backlit 16-character LCD.
Arming Modes: AWAY, HOME, AWAY-INSTANT, HOME-
INSTANT, LATCHKEY, FORCED, BYPASS.
Alarm inhibited during a single arming period (swinger
stop) after: 1, 2, 3, alarm/tamper/fault, or not inhibited
(programmable / selectable).
Alarm Types: Silent alarm, siren alarm or sounder
(internal) alarm, in accordance with zone attributes.
Siren Signals: Continuous
(intrusion / 24 hours / panic);
triple pulse - pause - triple pulse...
(fire).
Siren (bell) Timeout: Programmable
Internal Sounder Output: At least 85 dBA at 10 ft (3 m)
Supervision: Programmable time frame for inactivity alert
Special Functions:
- Speech and sound control
- X10 - an international and open industry standard for
communication among electronic devices used for home
automation (up to fifteen X-10 units)
- Chime zones
- Diagnostic test and event log
- Local and Remote Programming over Telephone, GSM
/GPRS connections
- Calling for help by using an emergency transmitter
- Tracking inactivity of elderly, physically handicapped and
infirm people
- Message center (recording and playback)
- Two-way voice communication
Data Retrieval: Status, alarm memory, trouble, event log.
Real Time Clock (RTC): The control panel keeps and
displays time and date. This feature is also used for the log file
by providing the date and time of each event. In addition, it is
used for the Scheduler where activity of a device is performed
according to a specific time and date selection.
Compliance with U.S. Standards:
Meets FCC Part 15 and Part 68 requirements. UL1637,
UL1635, UL1023, UL985, ULC-S545-02, ULC C1023, SIA
CP01
Compliance with Canadian Standards:
Meets RSS 210, ULC S545-02, ULC C1023, CSA C22.2#205
Compliance with CE Standards:
EN 50131-3, EN301489-3,7, EN 50130-4, EN60950, Aka
ETSI TS 0210, ATS-3
According to the European standard EN50131-1, the
PowerMax Pro security grading is 2 – "low to medium risk"
and environmental classification is II – "indoor general" and
the power supply type is A.
The PowerMax Pro is compatible with the RTTE
requirements - Directive 1999/5/EC of the European
Parliament and of the Council of 9 March 1999.
GSM standards:
Europe : Complies with CE standards 3GPP TS 51.010-1,
EN 301 511, EN301489-7
USA: FCC 47 Part 22 (GSM850) and Part 24 (GSM
1900).
EMC standard: FCC 47 Part 15.
SAR standards: FCC rule 2.1093, FCC Docket 96-326 &
Supplement C to OET Bulletin 65
