MGW Diamond Multi-Channel HEVC and H.264 Portable Encoder
User Manual, Version 1.6 28
To set the channel parameters:
1. From the main menu, select Channels.
2. Set the following parameters as required in each section and click Apply.
NOTE:
• When switching from HEVC to H.264 (or from H.264 to HEVC), click apply before you adjust any of the
Advanced Settings fields.
• Fields and optional settings in each one of the sections are automatically adjusted when you switch from
HEVC to H.264 channels to display only the settings and the parameters that are applicable to the selected
channel.
• A green frame appears when entered value is valid (see figure below).
• A red frame appears when the entered value is not valid.
• To apply changes to one or more fields you must click the Apply button on the bottom right. When exiting the
settings screen or starting a channel without applying the settings, the previous settings will apply.
Select the active source interface.
Displays the detected video/ audio format.
Select the box to force test pattern (color bar) for testing purposes.
Select the audio source (Embedded or external Analog Audio).
Select the audio sampling rate (Analog Audio only).
Select the embedded audio pair (SDI Embedded Audio only).
