Using the MGW Diamond Interface
MGW Diamond Functions
The followings are available at all times (regardless which menu item is selected):
• Dashboard Frame - top of page from which channels are controlled and monitored. Rows
represent the H.264 or HEVC channels. Up to 4x 1080p60 channel instances can be each
configured with its own input, encoding standard (H.264 or HEVC), bitrate, resolution,
frame rate. Those 4x1080p60 channels can be split in a Primary and Secondary stream for
a total of eight stream output (each stream can be configured with its own encoding
standard - H.264 or HEVC - bitrate, resolution, frame rate).
• Menus – Provide a centralized access to monitor, configure and control the MGW Diamond
Encoder.
• Help – An inline help manual.
• Logout - Allows you to log out of the application.
