2.1 - PLC CONTROLLER
Schematics & Parts mySelective.com
CHAPTER 2 3
2.1.1.2 RACK 1 - SLAVE 1
F
IGURE 2.3 RACK 1 - SLAVE 1
F
IGURE 2.4 SETTINGS CARDS
POS DESCRIPTION PA RT N UM BE R
A IMC 715 POWER REGULATOR 38100
B
C IMC 740 SLAVE CPU 38102
D IMC 710 BACKPLANE 38099
SL1 IMC 763 DIGITAL INPUT BOARD 41019
SL2 IMC 753 DIGITAL INPUT BOARD 38104
SL3*
SL4*
SL5 IMC 757 DIGITAL OUTPUT 38107
SL6 IMC 757 DIGITAL OUTPUT 38107
SL7 IMC 757 DIGITAL OUTPUT 38107
A
B
C
D
* = optional
*
*
12
3
45
Jumper settings
S
L
2
IM
C
751 analog input
S
L
9
IM
C
75
6
serial communication contr.
EPROM
V2.2
All inputs on ”I”
