Vitronics Soltec mySelective 6748 - Gripper

2.28 - GRIPPER ADJUSTMENT
Schematics & Parts mySelective.com
CHAPTER 2 39
2.28.3 GRIPPER
FIGURE 2.49 GRIPPER
cylinder
pin positioning
8 MM BOLT FOR ADJUSTING
CYLINDER
BARS
HEXAGON M5 FOR
ADJUSTING CYLINDER
POSITIONS
POSITION IN PCB
SCREW FOR ADJUSTING PIN
pin positioning
PCB
PCB fixed in gripper
TOPVIEW
GRIPPERS
PIN POSITIONING
PIN POSITIONING
PCB IN GRIPPER
