PARTS
8 CHAPTER 2
2.6 SAFETY MODULE
FIGURE 2.10 SAFETY MODULE
Part nr. 41548
Description Relay safety Schmersal AES 3075
K6 Main controlbox
Check jumper settings:
To check this, the housing cover can be removed. The PCB board with the jumpers is visible.
Check the jumpers as shown in Figure 2.11
2.6.1 JUMPER SETTINGS SAFETY MODULE
FIGURE 2.11 JUMPER SETTINGS SAFETY MODULE
S1 S2
S3 S4
