DLP Projector - User’s Manual
Operation Command Values
fan.pos = ? 0 = Normal
1 = Vertical
2 = Down
zoomio + - + => Zoom out
- => Zoom in
focus + - + => Focus Near
- => Focus Far
vert.offset + - + => Up
- => Down
horiz.offset + - + => Right
- => Left
lens.load = 1~10 set of lens memory (Load)
lens.save = 1~10 set of lens memory (Save)
lens.center (execute) Midposition shift
h.keystone = ? + - -350~+350
v.keystone = ? + - -200~+200
warp.rotat = ? + - -20 ~ +20 (in ¼ 1/4 unit)
warp.pinbrl = ? + - -100 ~ +100
warp.tlc.x
warp.tlc.y
= ? + - ‘x: -192 ~ +192
‘y: -120 ~ +120
warp.trc.x
warp.trc.y
= ? + - ‘x: -192 ~ +192
‘y: -120 ~ +120
warp.blc.x
warp.blc.y
= ? + - ‘x: -192 ~ +192
‘y: -120 ~ +120
warp.brc.x
warp.brc.y
= ? + - ‘x: -192 ~ +192
‘y: -120 ~ +120
warp.cust = ? 0 = Off
1 = On
warp.reset (execute)
blank.top = ? + - 0 ~ 360
blank.btm = ? + - 0 ~ 360
blank.left = ? + - 0 ~ 534
blank.right = ? + - 0 ~ 534
blank.rst (execute)
eb.stat (Edge Blend) = ?
eb.wht.top = ? + - 0, 200 ~ 500
eb.wht.btm = ? + - 0, 200 ~ 500
eb.wht.left = ? + - 0, 200 ~ 800
eb.wht.right = ? + - 0, 200 ~ 800
eb.blk.top = ? + - 0, 8, 16, 24, 32
eb.blk.btm = ? + - 0, 8, 16, 24, 32
eb.blk.left = ? + - 0, 4, 8, 12, 16, 20, 24, 28, 32
eb.blk.right = ? + - 0, 4, 8, 12, 16, 20, 24, 28, 32
eb.all = ? + - 0 ~ 32
eb.red = ? + - 0 ~ 32
eb.green = ? + - 0 ~ 32
eb.blue = ? + - 0 ~ 32
eb.reset (execute)
