Vivitek D8800 - D8010 W

DLP Projector - User’s Manual
70
D8010W
 D88-WF18501
Focus adjustable range 40”~500”
Optical performance range 50”~300”
Wide Fix WIDE TELE
Projection Distance L(M) Diagonal
TR
Width Height
Diagonal TR
Width Height
Wide Tele (inch) A(M) C(M) B D
0.67 40 0.78 0.86 0.54
0.85 50 0.79 1.08 0.67
1.03 60 0.80 1.29 0.81
1.39 80 0.81 1.72 1.08
1.75 100 0.81 2.15 1.35
2.11 120 0.82 2.58 1.62
2.64 150 0.82 3.23 2.02
3.18 180 0.82 3.86 2.42
3.54 200 0.82 4.31 2.69
5.33 300 0.83 6.46 4.04
7.13 400 0.83 8.62 5.38
8.92 500 0.83 10.77 6.73
 D88-WZ01
Focus adjustable range 40”~500”
Optical performance range 50”~300”
Wide Fix WIDE TELE
Projection Distance L(M) Diagonal
TR
Width Height
Diagonal TR
Width Height
Wide Tele (inch) A(M) C(M) B D
1.11 1.60 40 1.29 0.86 0.54 40 1.86 0.86 0.54
1.40 2.01 50 1.29 1.08 0.67 50 1.86 1.08 0.67
1.69 2.43 60 1.31 1.29 0.81 60 1.88 1.29 0.81
2.27 3.25 80 1.32 1.72 1.08 80 1.89 1.72 1.08
2.85 4.08 100 1.32 2.15 1.35 100 1.90 2.15 1.35
3.43 4.90 120 1.33 2.58 1.62 120 1.90 2.58 1.62
4.30 6.14 150 1.33 3.23 2.02 150 1.90 3.23 2.02
5.17 7.38 180 1.34 3.86 2.42 180 1.91 3.86 2.42
5.75 8.20 200 1.33 4.31 2.69 200 1.90 4.31 2.69
8.65 12.33 300 1.34 6.46 4.04 300 1.91 6.46 4.04
11.55 16.45 400 1.34 8.62 5.38 400 1.91 8.62 5.38
14.45 20.58 500 1.34 10.77 6.73 500 1.91 10.77 6.73
