DLP Projector - User’s Manual
CONTROLS AND FUNCTIONS
D8800/D8900/D8010W at a Glance
Air outlet
Air outlet
Air outlet
Adjustable
feet*4
Power inlet
Rear Infre-red window
(remote control)
Power switch
Air inlet
Air inlet
y Air outlet
Warm air exits the projector through this vent. Ensure
that it is not blocked.
y Air inlet
Internal fans draw cool air into the projector through
this vent.
y Adjustable feet
Use these when the projector is installed in a table-
top configuration to level the image and/or adjust the
projection angle.
y Power Inlet
For input power from wall outlet to projector.
y Rear Infre-red window
For receive the remote controller’s message.
