DLP Projector - User’s Manual
 D88-ST001
Focus adjustable range 40”~500”
Optical performance range 50”~300”
Wide Fix WIDE TELE
Projection Distance L(M) Diagonal
TR
Width Height
Diagonal TR
Width Height
Wide Tele (inch) A(M) C(M) B D
1.45 1.93 40 1.69 0.86 0.54 40 2.24 0.86 0.54
1.83 2.42 50 1.71 1.08 0.67 50 2.26 1.08 0.67
2.21 2.92 60 1.72 1.29 0.81 60 2.27 1.29 0.81
2.97 3.92 80 1.73 1.72 1.08 80 2.28 1.72 1.08
3.73 4.92 100 1.74 2.15 1.35 100 2.29 2.15 1.35
4.49 5.91 120 1.74 2.58 1.62 120 2.29 2.58 1.62
5.63 7.41 150 1.75 3.23 2.02 150 2.3 3.23 2.02
6.77 8.9 180 1.75 3.88 2.42 180 2.3 3.88 2.42
7.53 9.9 200 1.75 4.31 2.69 200 2.3 4.31 2.69
11.4 14.9 300 1.76 6.46 4.04 300 2.31 6.46 4.04
15.13 19.87 400 1.76 8.62 5.38 400 2.31 8.62 5.38
18.93 24.85 500 1.76 10.77 6.73 500 2.31 10.77 6.73
 D88-SMLZ01
Focus adjustable range 40”~500”
Optical performance range 50”~300”
Wide Fix WIDE TELE
Projection Distance L(M) Diagonal
TR
Width Height
Diagonal TR
Width Height
Wide Tele (inch) A(M) C(M) B D
1.87 3.15 40 2.18 0.86 0.54 40 3.66 0.86 0.54
2.36 3.96 50 2.2 1.08 0.67 50 3.68 1.08 0.67
2.85 4.77 60 2.21 1.29 0.81 60 3.69 1.29 0.81
3.82 6.39 80 2.22 1.72 1.08 80 3.71 1.72 1.08
4.8 8 100 2.23 2.15 1.35 100 3.72 2.15 1.35
5.78 9.62 120 2.24 2.58 1.62 120 3.72 2.58 1.62
7.24 12.04 150 2.24 3.23 2.02 150 3.73 3.23 2.02
8.7 14.47 180 2.25 3.88 2.42 180 3.73 3.88 2.42
9.68 16.08 200 2.25 4.31 2.69 200 3.73 4.31 2.69
14.56 24.16 300 2.26 6.46 4.04 300 3.74 6.46 4.04
19.44 32.25 400 2.26 8.62 5.38 400 3.74 8.62 5.38
24.32 40.33 500 2.26 10.77 6.73 500 3.74 10.77 6.73
