DLP Projector - User’s Manual
72
 D88-LOZ101
Focus adjustable range 40”~500”
Optical performance range 50”~300”
Wide Fix WIDE TELE
Projection Distance L(M) Diagonal
TR
Width Height
Diagonal TR
Width Height
Wide Tele (inch) A(M) C(M) B D
3.17 4.83 40 3.69 0.86 0.54 40 5.62 0.86 0.54
4.00 6.08 50 3.70 1.08 0.67 50 5.63 1.08 0.67
4.83 7.32 60 3.74 1.29 0.81 60 5.67 1.29 0.81
6.48 9.80 80 3.77 1.72 1.08 80 5.70 1.72 1.08
8.14 12.29 100 3.78 2.15 1.35 100 5.71 2.15 1.35
9.79 14.77 120 3.79 2.58 1.62 120 5.73 2.58 1.62
12.27 18.50 150 3.80 3.23 2.02 150 5.73 3.23 2.02
14.75 22.22 180 3.82 3.86 2.42 180 5.76 3.86 2.42
16.41 24.71 200 3.81 4.31 2.69 200 5.73 4.31 2.69
24.68 37.13 300 3.82 6.46 4.04 300 5.75 6.46 4.04
32.95 49.55 400 3.82 8.62 5.38 400 5.75 8.62 5.38
41.22 61.97 500 3.83 10.77 6.73 500 5.75 10.77 6.73
 D88-LOZ201
Focus adjustable range 40”~500”
Optical performance range 50”~300”
Wide Fix WIDE TELE
Projection Distance L(M) Diagonal
TR
Width Height
Diagonal TR
Width Height
Wide Tele (inch) A(M) C(M) B D
4.65 7.42 40 5.41 0.86 0.54 40 8.63 0.86 0.54
5.89 9.35 50 5.46 1.08 0.67 50 8.66 1.08 0.67
7.13 11.28 60 5.53 1.29 0.81 60 8.74 1.29 0.81
9.60 15.13 80 5.58 1.72 1.08 80 8.80 1.72 1.08
12.08 18.99 100 5.62 2.15 1.35 100 8.83 2.15 1.35
14.55 22.85 120 5.64 2.58 1.62 120 8.86 2.58 1.62
18.27 28.63 150 5.66 3.23 2.02 150 8.87 3.23 2.02
21.98 34.42 180 5.69 3.86 2.42 180 8.92 3.86 2.42
24.45 38.28 200 5.67 4.31 2.69 200 8.88 4.31 2.69
36.83 57.56 300 5.70 6.46 4.04 300 8.91 6.46 4.04
49.20 76.85 400 5.71 8.62 5.38 400 8.91 8.62 5.38
61.58 96.13 500 5.72 10.77 6.73 500 8.93 10.77 6.73
