Head
1
2
6
7
5
3
1 4 8
1.Clutch handle
2.Left brake switch
3. Gauge
4.Fuel tank lock
5.Ignition switch
6.Front brake main oil
cup
7.Right brake switch
and the oiler
8. Front brake handle
