Fuse
Electrical box Fuse box
63
F1 EFI Power
Supply Fuse
15A
F2 Engine Oil
Pump Power
Fuse
10A
F3 Fan Power
Fuse
15A
F4Spare Fuse
15A
F6Spare Fuse
15A
F5Spare Fuse
10A
F7Spare Fuse
10A
Spare Fuse
30A
Spare Fuse
10A
Vehicle Power Fuse
30A
Solenoid Valve
Power Fuse
10A
Motor Power Fuse
25A
Signal System
Fuse
10A
· Before replacing the fuse, the fault cause must be detected and
eliminated.
· This model installs an electrical box (with internal integrated
relay) and a fuse box.
· The specifications and uses of all fuses are explained.
-Main fuse (30A): control the power supply of the EFI system,
ABS system, other electric loads (instruments, lamps, etc.) of the
whole vehicle and the charging circuit of the battery. Spare fuse:
30A (1 PCS- Green- In the fuse box).
-ABS system motor fuse (25A): control the power supply of ABS
anti-lock system motor.
-ABS system solenoid valve fuse (10A): control the power supply
of ABS anti-lock system solenoid valve.
-Signal system fuse (10A): control the power supply of instruments,
lamps, horns, flashers, side bracket flameout switches, starting
relays, etc. - Red- In the fuse boxSpare fuse: 10A (1 pcs ).
-EFI system fuse (15A). Control ECU of EFI system, oxygen sensor,
ECU diagnostic interface, carbon canister solenoid valve,
fuel injector, ignition coil and other electric injection system
power supply. Spare fuse: 15A (1 pcs-blue-inside electric box).
-Fan fuse (15A): control the power supply of the cooling fan.
Spare fuse: 15A (1 pcs-red-inside electric box).
-Fuel pump fuse (10A): controls the power supply to the fuel pump.
Spare fuse: 10A (2 pcs-red-inside electric box).
