VOLTCRAFT DSO Four-Channel Series User Manual

9.Technical Specifications
117
Data Bits 5 bit, 6 bit, 7 bit, 8 bit
I2C Trigger
Trigger Condition
Start, Restart, Stop, ACK Lost, Address,
Data, Addr/Data
Address Bits 7 bit, 8 bit, 10 bit
Address Range 0 to 127, 0 to 255, 0 to 1023
Byte Length 1 to 5
SPI Trigger
Trigger Condition Timeout
Timeout Value 30 ns to 10 s
Data Bits 4 bit to 32 bit
Data Line Setting H, L, X
CAN Trigger
Signal Type CAN_H, CAN_L, TX, RX
Trigger Condition
Start of Frame, Type of Frame, Identifier,
Data, ID & Data, End of Frame, Missing
Ack, Bit Stuffing Error
Baud Rate Common, Custom
Sample Point 5% to 95%
Frame Type Data, Remote, Error, Overload
Waveform Generator (optional)
Performance
Characteristics
Instruction
Max Frequency Output
25 MHz
Sample Rate 125 MSa/s
Channel
1 or 2
Vertical Resolution
14 bits
Amplitude Range
2 mVpp - 6 Vpp
Waveform length
8K
Standard Waveforms
Sine, Square, Ramp, and Pulse
Arbitrary Waveforms
Exponential Rise, Exponential Fall, Sin(x)/x, Step Wave,
Noise, and others, total 46 built-
in waveforms, and
user-defined arbitrary waveform
