5.Use the Arbitrary Function Generator (Optional)
ln Natural logarithm function
Cubic Cubic function
Cauchy Cauchy distribution
Besselj BesselI function
Bessely BesselII function
Erf Error function
Airy Airy function
Windows
Rectangle Rectangle window
Gauss Gauss distribution
Hamming Hamming window
Hann Hanning window
Bartlett Bartlett window
Blackman Blackman window
Laylight Laylight window
Triang Triangle window (Fejer window)
Others
DC DC signal
Heart Heart signal
Round Round signal
LFMPulse Linear FM pulse
Rhombus Rhombus signal
Cardiac Cardiac signal
Noise Noise signal
Frequency Response Analysis
The Frequency Response Analysis (FRA) feature controls the built-in waveform generator
to sweep a sine wave across a range of frequencies while measuring the input to and
output from a device under test. At each frequency, gain and phase are measured and
plotted on a frequency response Bode chart. When the frequency response analysis
completes, you can move a marker across the chart to see the measured gain and phase
values at each frequency point. You can also adjust the chart's scale and offset settings for
the gain and phase plots.
Note: If the signal is disturbed seriously, it is recommended to select Average in Acquire
Mode before running the analysis, the averages can only be set as 4 or 16, and then run the
analysis.
Push the Utility button, select Function in the bottom menu, select FRA in the left menu.
The description of FRA Menu is shown as the follows:
Setting Description
To Next Page
