VOLTCRAFT DSO Four-Channel Series User Manual

9.Technical Specifications
113
9. Technical Specifications
Unless otherwise specified, the technical specifications applied are for DSO
four-channel series only, and Probes attenuation set as 10X. Only if the oscilloscope
fulfills the following two conditions at first, these specification standards can be
reached.
 This instrument should run for at least 30 minutes continuously under the
specified operating temperature.
 If change of the operating temperature is up to or exceeds 5℃, do a
"Self-calibration" procedure (see "How to Implement Self-calibration" on P13).
All specification standards can be fulfilled, except one(s) marked with the word
"Typical".
Oscilloscope
Performance Characteristics
Instruction
Bandwidth
DSO-6084
80 MHz
DSO-6104
100 MHz
DSO-6204
200 MHz
Vertical Resolution (A/D)
8 bits
Channel
4
Waveform Capture Rate
DSO-6084
DSO-6104
45,000 wfms/s
DSO-6204
70,000 wfms/s
Multi-level Gray Scale Display &
Color Temperature Display
(Use gray scale to indicate frequency of
occurrence, where frequently occurring
waveform are bright.)
Support
Acquisition
Mode
Normal, Peak detect, Averaging
Sample rate
(real time)
DSO-6084
DSO-6104
Four CH 250 MSa/s
Dual CH* 500 MSa/s
Single CH
1 GSa/s
DSO-6204
Four CH
500 MSa/s
Dual CH*
1 GSa/s
Single CH
1 GSa/s
Input
Input coupling DC, AC , Ground
Input impedance 1 MΩ±2%, in parallel with 15 pF±5 pF
Input coupling 0.001X - 1000X, step by 1 – 2 - 5
Max input voltage
400 V (DC + AC Peak)
Bandwidth limit
20 MHz, full bandwidth
