VOLTCRAFT DSO Four-Channel Series User Manual

4.Advanced User Guidebook
73
How to Implement the Auxiliary System Function Setting
●Config
Push the Utility button, select Function in the bottom menu, select Configure in
the left menu.
The description of Configure Menu is shown as the follows:
●Display
Push the Utility button, select Function in the bottom menu, select Display in the
left menu.
The description of Display Menu is shown as the follows:
●Adjust
Push the Utility button, select Function in the bottom menu, select Adjust in the
left menu.
The description of Adjust Menu is shown as the follows:
Function Menu
Setting
Description
Language
Choose the display language of the operating
system.
Set Time
Display
ON
OFF
On/Off the date display
Hour Min
Setting Hour/Minute
Day Month
Setting Date/Month
Year
Setting Year
KeyLock
Lock all keys. Unlock method: push Trigger
Menu button in trigger control area, then push
Force button, repeat 3 times.
About
Version number and serial number showing
Function Menu
Setting
Description
BackLight
0% - 100%
Turn the M knob to adjust the backlight.
Graticule Select the grid type
Battery
ON
OFF
Turn on or off the battery display
Menu Time
OFF, 5s - 30s
Set the disappear time of menu
