4.Advanced User Guidebook
Figure 4-16: Play back waveform by software
How to Clone and Recall a waveform
Push Save button. Select Type in the bottom menu, in the left menu, turn the M knob
to select Clone.
You can clone one or two channel waveforms between two cursors, and save it as a
cloned waveform into the internal memory or a USB memory device. You can save
four cloned waveforms in the instrument internal memory. The cloned waveform files
saved to a USB memory device are saved with the extension "ota".
If the optional Arbitrary Function Generator is available in your instrument, you can
output the stored waveform from a file in the internal memory or in a USB memory
device; and the waveform between two cursors can be output directly without save
operation.
Clone Wave menu shows as follows:
Select the clone function.
Source
Out1
Out2
Out1&Out2
Select the source mode.
The cloned waveform includes one waveform, which
will be used for AG Out1
The cloned waveform includes one waveform, which
will be used for AG Out2
The cloned waveform includes two waveforms, whic
h
will be used for AG Out1 and AG Out2
Out1
CH1 CH2
Select the source, which will be used for AG Out1
Out2
CH1 CH2
Select the source, which will be used for AG Out2
To Next Page
