VOLTCRAFT DSO Four-Channel Series User Manual

9.Technical Specifications
118
General Technical Specifications
Display
Display Type
8" Colored LCD (Liquid Crystal Display)
Display Resolution
800 (Horizontal) × 600 (Vertical) Pixels
Display Colors
65536 colors, TFT screen
Output of the Probe Compensator
Output Voltage
(Typical)
About 3.3 V, with the Peak-to-Peak voltage ≥1 MΩ.
Frequency (Typical)
Square wave of 1 KHz
Power
Mains Voltage 100V – 240 VACRMS, 50/60 Hz, CAT Ⅱ
Power Consumption
DSO-6084
DSO-6104
＜15 W
DSO-6204
＜
24 W
Power Fuse 2 A, T class, 250 V, Φ5 x 20 mm
Battery (optional) 3.7V, 13200mAh
Environment
Temperature
Working temperature: 0
℃
- 40
℃
Storage temperature: -20
℃
- 60
℃
Relative Humidity
≤ 90%
Height
Operating: 3,000 m
Non-operating: 15,000 m
Cooling Method
Fan cooling
Mechanical Specifications
Dimension
340 mm × 177 mm × 90 mm (L*H*W)
Weight
Approx. 2.6 kg (without accessories)
Interval Period of Adjustment:
One year is recommended for the calibration interval period.

VOLTCRAFT DSO Four-Channel Series Specifications

General

Brand	VOLTCRAFT
Model	DSO Four-Channel Series
Category	Test Equipment
Language	English
