VOLTCRAFT DSO Four-Channel Series User Manual

9.Technical Specifications
114
Performance Characteristics
Instruction
Channel to channel
isolation
50Hz: 100 : 1
10MHz: 40 : 1
Time delay between
channel (typical)
150ps
Horizontal
System
Sampling rate range
DSO-6084
DSO-6104
Four CH 0.05 Sa/s - 250 MSa/s
Dual CH*
0.05 Sa/s - 500 MSa/s
Single CH
0.05 Sa/s - 1 GSa/s
DSO-6204
Four CH 0.05 Sa/s - 500 MSa/s
Dual CH*
0.05 Sa/s - 1 GSa/s
Single CH
0.05 Sa/s - 1 GSa/s
Interpolation (Sinx)/x, x
Record length
4 channels ON: max 10M;
2 channels ON: max 20M;
1 channel ON: max 40M.
Scanning speed (S/div)
DSO-6084
DSO-6104
2ns/div - 1000s/div,
step by 1 – 2 - 5
DSO-6204
1ns/div - 1000s/div,
step by 1 – 2 - 5
Sampling rate / relay
time accuracy
±2.5 ppm max (Ta = +25℃)
Interval(△T) accuracy
(DC - 100MHz)
Single
：
±(1 interval time+1 ppm×reading+0.6 ns);
Average>16：
±
(1 interval time +1 ppm×reading+0.4 ns)
Vertical system
Sensitivity 1 mV/div - 10 V/div
Displacement
DSO-6084
DSO-6104
±2 V (1 mV/div – 50 mV/div)；
±20 V (100 mV/div – 1 V/div)；
±200 V (2 V/div – 10 V/div)
DSO-6204
±2 V (1 mV/div – 100 mV/div)
；
±20 V (200 mV/div – 1 V/div)；
±200 V (2 V/div – 10 V/div)
Analog bandwidth
DSO-6084
80 MHz
DSO-6104
100 MHz
DSO-6204
200 MHz
Single bandwidth
DSO-6084
DC to 80 MHz
DSO-6104
DC to 100 MHz
DSO-6204
DC to 200 MHz
Low Frequency
≥10 Hz (at input, AC coupling, -3 dB)
Rise time (at input,
Typical)
DSO-6084
≤4.375 ns
DSO-6104
≤ 3.5 ns
DSO-6204
≤ 1.75 ns
