VOLTCRAFT DSO Four-Channel Series User Manual

9.Technical Specifications
115
Performance Characteristics
Instruction
DC gain accuracy
DSO-6084
DSO-6104
1 mV
±4%
≥2 mV
±3%
DSO-6204
1 mV
±3%
≥2 mV
±2%
DC accuracy (average)
Delta Volts between any two averages of
≥16 waveforms acquired with the same
scope setup and ambient conditions (△V):
±(3% rdg + 0.05 div)
Waveform inverted ON/OFF
Measurement
Cursor
△
V,
△
T,
△
T&
△
V between cursors,
auto cursor
Automatic
Period, Frequency, Mean, PK-PK, RMS,
Max, Min, Top, Base, Amplitude,
Overshoot, Preshoot, Rise Time, Fall Time,
+Pulse Width, -Pulse
Width, +Duty Cycle,
-Duty Cycle, Delay A→B
, Delay
A→B ,
Cycle RMS, Cursor RMS, Screen
Duty, Phase A→B , Phase A→B , +Pulse
Count, -Pulse Count, Rise Edge Count, Fall
Edge Count, Area, and Cycle Area.
Waveform Math
＋
,
－
, *, / ,FFT, FFTrms, Intg, Diff, Sqrt,
User Defined Function, digital filter (low
pass, high pass, band pass, band reject)
Decoding Type
RS232, I
2
C, SPI, CAN
Waveform storage 100 waveforms
Lissajous
figure
Bandwidth
Full bandwidth
Phase
difference
±3 degrees
Communication
port
USB Host, USB Device; Trig Out(Pass/Fail); LAN port
Printer
Compatibility
PictBridge
Counter Support
* For DSO-6084 and DSO-6104, Max Sample rate (real time) for Dual CH should meet either
following condition:
1. CH1&CH2 on, CH3&CH4 off;
2. CH1&CH2 off, CH3&CH4 on.
For DSO-6204, Max Sample rate (real time) for Dual CH should meet the following condition:
CH1 and CH2 can not be turned on simultaneously, CH3 and CH4 can not be turned on
simultaneously.
