4.Advanced User Guidebook
Save
Save the current display screen. The file
can be only stored in a USB storage, so a
USB storage must be connected first. The
file name is editable. The file is stored in
BMP format.
Save and Recall the Waveform
The oscilloscope can store 100 waveforms, which can be displayed with the current
waveform at the same time. The stored waveform called out can not be adjusted.
In order to save the waveform of CH1, CH2 and Math into the address 1, the
operation steps should be followed:
1. Turn on CH1, CH2 and Math channels.
2. Push the Save button.
3. Saving: Select Type in the bottom menu, select Wave in the left menu.
4. Select Storage in the bottom menu, select Internal in the right menu.
5. Select Source in the bottom menu, check CH1, CH2, Math in the right menu for
Source.
6. Select Object & Show in the bottom menu, select Wave1 as object address in the
left menu.
7. Select Save in the bottom menu to save the waveform.
8. Recalling: Select Object & Show in the bottom menu, select Wave1 in the left
menu. In the right menu, select Show as ON, the waveform stored in the address
will be shown, the address number and relevant information will be displayed at
the top left of the screen.
In order to save the waveform of CH1 and CH2 into the USB storage as a BIN file,
the operation steps should be followed:
1. Turn on CH1 and CH2 channels.
2. Push the Save button.
3. Saving: Select Type in the bottom menu, select Wave in the left menu.
4. Select Storage in the bottom menu, select External in the right menu.
5. Select Type in the bottom menu, select BIN in the right menu as the storage
format.
6. Select Source in the bottom menu, check CH1, CH2 in the right menu for
Source.
7. Select Save in the bottom menu, an input keyboard used to edit the file name will
