VOLTCRAFT VC-590OLED - Page 77

7Capacitance
Range Accuracy Resolution
60.00 nF ±(4% + 20) 0.01 nF
600.0 nF 0.1 nF
6.000μF 0.001μF
60.00μF 0.01μF
600.0μF 0.1μF
6.000 mF ±(8.0% + 20) 0.001 mF
60.00 mF Notspecied 0.01 mF
Overload protection 1000 V
8Diode test
Test voltage Resolution
approx. 3.3 V 0.001 V
Overload protection: 1000 V
9Acoustic continuity check
Test voltage Resolution
approx. 1.2 V 0.1Ω
Overloadprotection:1000V,Measuringrangemax.600Ω;<10Ωcontinuoustone
10NCV Non-contact AC voltage test
Test voltage Distance
>100 - 750 V/AC max. 10 mm
Frequency: 45 - 400 Hz
Never exceed the maximum permissible input values. Do not touch any circuitry
or connection points when voltages exceeding 33 V/ACrms or 70 V/DC might be
applied. Risk of fatal injury!
77
