(see fold-out page)
1 No-contact voltage detector
2 LC display
3 POWER button on the VC130-1/150-1
SELECT button on the VC170-1 for
function switching
4 Rotary switch
5 COM measuring socket (reference potential)
6 10 A measuring socket
7 mAµA measuring socket
8 V measuring socket
9 HOLD button
10 Battery compartment
11 Stand clamp
This device left the manufacture’s factory in a safe and perfect condition.
We kindly request that you as a user observe the safety instructions and warnings contained in this operating
manual to preserve this condition and to ensure safe operation!
