1Engaging the diff lock between axles.
J4017789
2 Set the bogie switch to the lower position.
The load is distributed so that the drive axle carries a
heavier load than previously. The bogie lamp is lit.
J7008415
To return to normal driving:
1 Put the bogie switch in the centre position
2 Disengage the diff lock
J7008420
Driving
163
