In relay and fuse box
The fuses in the electrical distributor unit are of the
blade fuse type, two different types are used. If a fuse
in the same fuse holder has to be changed frequently,
the truck should be taken to the workshop for a check
on the electrical system.
Warning!
Always use the stipulated size of
fuse. Never use a higher fuse.
Note!
Switch off the current before
changing a fuse. The fuse holder can
burn up if the current is on.
Blade fuses
Fuse no. Use Fuse rating
F 1 TPM 10 A
F 2 Lighting, cargo area 10 A
F 3 Loading lamp, fifth-wheel lighting 10 A
F 4 Electrically adjustable seat, cab tilt pump, loading and fifth-
wheel lighting
5 A
F 5 Instrumentation (kl. 30) 5 A
F 6 Air drier 5 A
F 7 Vehicle control unit, electronic immobilizer 5 A
F 8 Instrumentation, TPM 5 A
F 9 Range interlock, area interlock (in gearbox) 5 A
F10 NOx sensor, road toll 5 A
F11 Control unit gear shifter 5 A
F12 Control unit transmission/retarder 10 A
F13 Windscreen wiper 15 A
F14 Cigarette lighter, lamp storage compartment, centre section 10 A
622
Fuses and relays
