The vehicle should remain stationary when the power
take-off is engaged.
The power take-off should not be engaged during
driving. If for some reason it must be engaged, then
gearshifting is not allowed.
On trucks with
I-shift
it will not be possible to change
gear if the power take-off is engaged while driving.
The desired gear must be selected while the truck is
stationary.
Engage power take-off
It does not matter which position the gear shifter is in.
1 Hold in the lock button on the switch
2 Press in the lower part of the switch
The indicator lamp lights and the display shows
PTO.
Disengage power take-off
Press in the upper part of the switch.
J0008081
J0008082
When the gearbox is in neutral it is possible to choose
between two gears, N1 and N2, with different speed
ranges.
1 Move the gear lever to N
2 Select N1 or N2 with the +/- button
3 See which gear is selected on the display
N2 allows about 30% higher engine speed than N1.
High range lock-up
High range lock-up is used when a PTO is installed in
the powertrain. The gearbox will start in high gear
when the vehicle is disengaged from the engine and
gearbox and the powertrain PTO is engaged. Lock-up
will already be active at low engine speed.
Engage
1 The engine must be idling at low speed
2 Move the gear lever to N
Driving
179
