Saving a program
Whenyou’vecomeupwithasoundyoulike,here’showto
save(write)it.
NOTE: Ifyouswitchtoadifferentprogramorturnoffthepow‐
erbeforesaving,thechangesyou’vemadewillbedis‐
carded,andthesetting s willreverttotheiroriginalstate.
1. PresstheWRITEswitch.
TheBank/Valuedispl
ayandtheprogrampedalLEDswill
blink.
2. Press the BANK UP or BANK DOWN pedal to select a

bank(01–25)oftheuserprograminwhichyouwantto
saveyoursettings.
Theselectedba nknumberwillblinkonth
eBank/Value
display.
3. Press the Pr
ogram 1–4 ped
als to select the desired user
program.
NOTE: Yoursettingswilloverwritetheprogramyouselect
here.Becarefulnottooverwriteanimportantpro‐
gramthatyouwanttokeep.Youcan’tsav
etoapre‐
setprogram(26–50).
HINT: IfyoudecidetocanceltheWriteoperation,pressthe
EXIT/TUNEswitch.Youwillreturntotheprevious
mode,andtheLEDwillstopblinking.
4. PresstheWRITEswitchonceagain.
Yoursettingswi llbewrittento theuserpro
gramyouse‐
lectedinstep2,andtheBank/Valuedisplayandthepro‐
grampedalLEDwillreturntoasteadilylitstate.
About the amp models, cabinet
models, and effect types
Thissectionprovidesdetailsabouttheampmodelsandstand
alonepedalsandcabinetmodels,andonthepedal1,2effects,
modulationeffects,delayeffects,andreverbeffect.
Thefollowingillustrationshowsthesignalflowwith inthe
ToneLabEX.
11 STAND
ALONE PEDALS
MODEL
GAIN
33 AMPS
POWER AMP
(Valve Reactor)
VALVE ECC83
(12AX7)
VOLUME
PEDAL
1
PEDAL
2
MODULATION
DELAY
REVERB
VOLUME
PEDAL
CABINET
MODEL
AMP/LINE
switch
OUTPUT
AMPS/S.A PEDALS
Amp models
Herewe’llexplainthe33differentampmodels.
HINT: Each amp model’s GAIN (adjusted by the top panel
GAINcontrol)canbe assignedtotheexpressionpedal
forcontrol.Fordetailsonhowtoassignaparameterto
theexpressionpedal,referto“Assigningafunction to
theexpressio
npedal(QuickAssign)”(p.31).
