Vox Tonelab EX User Manual

31
Using the expression pedal
for control
Expression pedal settings
TheToneLabEX’sprogramsassignvariousfunctionstothe
expressionpedal,allow ingyo u tocontrolnotonlywahor
volumebutmanyother kin dsofeffectparameterswiththe
expressionpedal.
HINT: If you select “VOX V847”  or “ VOX V845, ”  the expres‐
sionpedalwillautomaticallyfunctionasawahpedal.
Foreachprogram,youcanspecifywhichparameterwillbe
controlledbytheexpressionpedalandhowitwillbecon‐
trolled.
Whenyousaveaprogram,theposition(a
ngle)oftheexpres‐
sionpedalatthatmomentwillbesavedintheprogramasthe
parametervalue.Whenyouselectthatprogram,thevalue
savedintheprogramwillberecalledasthesettingofthe
assignedparameter.
Inthef
ollowingcases,howe
ver,thevalueisnotsaved.
•Volume
•Inputleveltothedela
yeffect
•Inputleveltothereverbeff
ect
•PITCHparameterofPITCH
•Cutof
ffrequencyofFILTRON
•VowelofTALKMOD
Assigning a function to the
expression pedal (Quick Assign)
OntheToneLabEX,it’seasytoassignaneffectparameteror
theeffectinputleveltotheexpressionpedal.
HINT: Fordetailsontheeffectparametersthatyoucanassign,
referto“Ab o u t theampmodels,cabinetmodels,andef‐
fecttypes”(p.15).
To assign a function to the expression pedal
Asanexample,here’showtoassigntheSPEEDparameterof
theU‐VIBEpedal2effecttotheexpressionpedal.
1. Turnontheeffect.
Inthisexa
mple,pressthePEDAL2on/offswitchtoturn

thepedaleffecton.
2. Usetheselectortoselectaeffect,andthenusetheED
IT
knob.
UsethePEDAL2selectortoselectU‐VIBE,andthe
nturn
theEDITknob.TheQuickAssignLEDwilllight.
3.
HolddowntheEXPRESSIONswitchforabouttwoseconds.
TheSPEEDparameterwillbeassignedtotheexpression
pedal;thebank/valuedisplay willind icate“ ”forone
second.
4. Ifdes
ired,savethissettingintheprogram.
Fordetailsonhowtosave,referto“Savingaprogram”(p.15).
NOTE: Thesettingsyoumadewillreturntotheiroriginal
valuesifyouswitchprogramsorturnoffthepower
beforesaving.

Vox Tonelab EX Specifications

General

Type	Multi-effects processor
Cabinet Models	11
USB	No
Expression Pedal	Built-in
Tuner	Yes
Effect Types	Overdrive, Distortion, Modulation, Delay, Reverb
Amp Models	11
Inputs	1 x Instrument
Outputs	2 x 1/4" (L/Mono, R), 1 x Headphones
MIDI	In, Out
Power Supply	AC adapter
