Introduction
Description
This safety label warns of the following dangers:
Cutting hazard. Cooling fan can cut when rotating. Stop engine before working on the
engine or cooling system.
Entanglement hazard.You can be pinched or entangled in the engine V-belt when the
engine is running. Stop engine before working on the engine.
Hot surface! Do not touch.
Burn hazard. Contents are under pressure. Do not remove cap.
Location
In the engine compartment
Description
Explains at which positon of the selection valve which control pattern is chosen (control
pattern “A“ or “B“). Check before starting the machine which controll pattern you have
chosen!
– see chapter 3.25 Changeover valve for control pattern’’B’’(option) on page 3-44
Location
Inside the cab
Description
Attention! Read and understand the Operator’s Manual before starting, operating, adjust-
ing,maintaining, or repairing the machine.
Location
Inside the cab on the right-hand side lining.
Description
Pinch point hazard. Always use the handles to open and close the front window!
Always lock the front window with both locks!
Location
In the upper right of the cab.
STOP
STOP
1000154002
Fig. 18: Warning label
1000173188
2
1
1
2
Fig. 19: Changeover valve for controll pattern options
Fig. 20: Read the Operator's Manual
Fig. 21: Opening and closing the front window
