5-26 BA EZ26 en/us* 1.0 * EZ26_01_510.fm
5 Operation
AUX III operation (Powertilt)
Crushing hazard due to rotating movements of the Powertilt unit!
Rotating the Powertilt unit can cause serious injury or death.
► Do not allow anyone to stay in the danger zone.
The Powertilt unit may only be installed and removed by a Wacker
Neuson service center!
For more information, see Easy Lock/Powertilt with Easy Lock
Operator’s Manual.
Fig. 154 (symbolic representation)
Function
1
1. Depending on the system used or the valid norm, the rotation of direction may differ.
Operation
Rotation to the left Press rocker switch A to the left
Rotation to the right Press rocker switch A to the right
