BA EZ26 en/us* 1.0 * EZ26_01_400.fm 4-29
Putting into operation 4
Status indicators
Symbol
Speed range 2
The control lamp (green) lights up if the speed 2 is active.
Charge indicator light
This indicator light (red) illuminates if the electrical system has a malfunction.
The battery is no longer or insufficiently charged.
Note: This indicator light also illuminates if the starting key is turned to position
2. The indicator light goes out after the engine is started.
Increase engine speed if the indicator light illuminates. The electrical system
works if the indicator light of the electrical system goes out within one minute.
Engine oil pressure
The indicator light (red) illuminates and the buzzer sounds.
• Stop the engine immediately and check the engine oil level.
• If the engine oil level is correct, contact a Wacker Neuson service center.
Note: The indicator light illuminates when the starter is turned on and goes out
as soon as the engine runs.
At low temperatures, the indicator light can illuminate a few seconds after the
engine is started.
Preheating
The indicator light (yellow) illuminates if the starting key is in position 2. Contact
an authorized service center if the indicator light does not go out.
Overload
The indicator light illuminates red and the buzzer sounds.
The permissible load diagram values are exceeded.
• Reduce the load until both the buzzer and the warning light go out –
see chapter “ Lifting gear applications” on page 5-44.
When the safe load indicator is switched on, the symbol is illuminated and the
buzzer sounds as a functional check.
Coolant temperature
If the segments reach the red range, the indicator light A illuminates and the
buzzer sounds.
Measures to be taken
• Let the engine run at high idling speed without any load.
• Wait until the temperature drops and the indicator light goes out.
• Stop the engine
• Check the coolant level.
