7-28 BA EZ26 en/us* 1.0 * EZ26_01_700.fm
7 Maintenance
Empty the water separator (main filter)
Empty the main filter if the fuel/water mixture rises to position D.
1. Stop and park the vehicle Stop the engine See āPreparing
lubricationā.
2. Prepare a suitable container for collecting the fuel/water mixture.
3. Open the engine cover.
4. Connect a suitable hose to the drain device A.
5. Open drain valve B.
6. Loosen bleed screw C.
7. Drain the fuel/water mixture into a receptacle (1).
8. Tighten bleed screw C.
9. Close drain valve B if nothing but fuel is visible in the sight glass (2).
10.Remove the hose.
11.Close and lock the engine cover.
Use a suitable container to collect fluids and lubricants as they flow out
and dispose of them in an environmentally friendly manner.
Fig. 243 (symbolic representation)
C
B
A
D
Fig. 244 (symbolic representation)
C
B
A
Fig. 245 (symbolic representation)
B
2
1
