9-16 BA EZ26 en/us* 1.0 * EZ26_01_900.fm
9 Technical data
Excavator forces
According to ISO 6015
Ground clearance/ground pressure
EZ26
Max. tearout force
(short stick)
15.3 kN (3440 lbf)
Max. tearout force
(long stick)
13.6 kN (3057 lbf)
Max. breakout force
at bucket tooth
22.5 kN (5058 lbf)
EZ26 EZ26 VDS
Ground clearance 280 mm (11 in) 285 mm (11 in)
Ground pressure > 0.27 kg/cm² (3.8 lbs/in²)
Steel chain ground pressure > 0.28 kg/cm² (4 lbs/in²)
