4-14 BA EZ26 en/us* 1.0 * EZ26_01_400.fm
4 Putting into operation
Adjusting the outside rear-view mirrors on left and right (option)
• Ensure sufficient visibility from the seat of the work areasite.
• Ensure maximum visibility to the rear.
• Ensure visibility of the rear left edge of the vehicle in the mirror on the left.
• Ensure visibility of the rear right edge of the vehicle in the mirror on the right.
Wacker Neuson recommends adjusting the mirrors with two persons.
Do not make any modifications that impair visibility. Otherwise the vehicle
does not meet the requirements for conformity and registration.
• Use safety-oriented ladders and work platforms for adjustment work on
the vehicle.
• Do not use vehicle parts or attachments as a climbing aid.
• Set the boom to travel position before adjusting the mirrors.
Fig. 95 (symbolic representation)
